- ELEMENT Fixed-charge back plate, permanently polarized condenser
- POLAR PATTERN Omnidirectional in hemisphere above mounting surface
- FREQUENCY RESPONSE 30-20,000 Hz
LOW FREQUENCY ROLL-OFF 80 Hz, 18 dB/octave
- OPEN CIRCUIT SENSITIVITY 31 dB (28.2 mV) re 1V at 1 Pa
- IMPEDANCE 200 ohms
- MAXIMUM INPUT SOUND LEVEL 132 dB SPL, 1 kHz at 1% T.H.D.
- DYNAMIC RANGE (typical) 111 dB, 1 kHz at Max SPL
- SIGNAL-TO-NOISE RATIO 73 dB, 1 kHz at 1 Pa
- PHANTOM POWER REQUIREMENTS 11-52V DC, 4 mA typical
- SWITCH Flat, roll-off
- WEIGHT 262 g (9.2 oz)
- DIMENSIONS 108.0 mm (4.25") maximum length,
84.0 mm (3.31") maximum width,
23.0 mm (0.91") maximum height
- OUTPUT CONNECTOR TB3M-type
- CABLE 7.6 m (25.0') long, 3.2 mm (0.13") diameter, 2-conductor, shielded cable with TA3F-type and XLRM-type connectors
- OPTIONAL INTERCHANGEABLE ELEMENTS UE-C cardioid (120°);
UE-H hypercardioid (100°)
- ACCESSORY FURNISHED Soft protective pouch
