Lake People LP-F612 2 x 1" 4 AES/EBU Splitter + 1" 8 WCLK/AES-id Splitter

MODULE 1 (AES/EBU Splitter) - 1 input, 4 outputs via XLR sockets, transformer balanced, impedance 110 ohms, according to AES 3/11 - High sensitive inputs to regenerate unproper or weak input signals - High output voltages (> 4 Veff) to drive long distances MODULE 2 (WCLK/AES-id Splitter) - 1 input and 8 outputs via BNC sockets, unbalanced, impedance 75 ohms - High sensitive inputs to regenerate unproper or weak input signals - High output voltages to drive long distances - Jumpers to switch the output impedance from 75 ohms to 50 ohms to drive improper WCLK inputs - Jumpers to switch to AES-3id operation - Jumpers to switch to “Superclock 256 Fs” - Failsafe operation through switchable Auto-Mode Multimode power supply 90 … 260V AC - 19”, 1 U stainless steel case, front dark grey MULTI-SYNC UNIT OPTION: The MULTI-SYNC UNIT option offers the following features: - 3 external inputs, sample rate 28 ... 210 kHz, AES/EBU, AES-id, WCLK - 1 AES-EBU sync output - Internal oscillators with 32, 44.1, 48, 88.2, 96, 176.4, 196 kHz - Auto-Mode, Format, Key-Lock und Mute switchable - Displays for: Sync-Source, Sample-Rate, Lock, Error, Mute, Pro/Con- Format, Auto-Mode, Key-Lock
